USING THE M204’S COMMAND SET: npsh Command Set 99

printer how to change between PCL and PostScript modes.

If no parameters are speciﬁed, the model defaults to the switching strings for

an HP LJIIIsi printer. pclswvar is the switching string to change modes to

PCL and psswvar is the switching string to change modes to PostScript.

Please see set var on page 104 to set a new variable with a particular switch

string or Variable Definitions on page 163 for the pre-deﬁned switching vari-

ables.

set model

modelname

type raw

Set the model speciﬁed to no sensing and no conversion. In this mode, there is

no ASCII to PostScript processing and no switching strings appended to the

jobs.

set model m4 header $ESC \&k2

sets the header string of the model m4 with five elements. Invokes CR inser-

tion.

When inputting a “

$” or a “&” and you’re using RSHD to execute this com-

mand, you must place a “

\” beforehand so the local shell interpreter doesn’t

parse it out.

set model m3 type pcl-ps $HP3-SWPCL $HP3-SWPS

sets the model m3 to switch printer modes between PCL and PostScript for an

HPLJIIIsi-compatible printer. The two variables deﬁned represent a PCL

switch string and a PostScript one.

See also: Models on page 78 and list model on page 87.

set prn1|prn2

arguments

Conﬁgure parallel I/O port parameters. The arguments can be the following

and if used with a “-”, the arguments will be reversed:

[-]ackmode Use the

ACK signal for the trigger of next data transfer. This

can generally be used with older printers. With “-”, the

BUSY signal is used as the trigger.

Examp

Note
